C Purlin Steel Roll Forming Machine With Hydraulic Punching 17 Forming Stations

Name: C Purlin Steel Roll Forming Machine With Hydraulic Punching 17 Forming Stations
Brand: TECHWELL
Price: 1 USD

Buy cheap C Purlin Steel Roll Forming Machine With Hydraulic Punching 17 Forming Stations product

Brand Name : TECHWELL

Model Number : TW-C300

Certification : CE

Place of Origin : China

MOQ : 1 Set

Price : Contact Us

Payment Terms : 40% T/T in advance, 60% T/T before shipment

Supply Ability : 20 sets

Delivery Time : 55-65 working days

Packaging Details : Standard packing

Material : GI, Carbon steel

Forming speed : 0-15m/min

Decoiler : Manual or hydraulic decoiler ( customer can choose )

Drive Type : 1.5' chain transmission

Encoder : OMRON Brand

Punching : Hydraulic Punching

Contact Now

Thickness 1.5-3.0mm, 17 Forming Stations C Purlin Roll Forming Machine With Hydraulic Punching

Main Specification of C Purlin Roll Forming Machine

Thickness 1.5-3.0mm, 17 Forming Stations C Purlin Roll Forming Machine With Hydraulic Punching
Material thickness	1.5-3.0mm
Material	GI, Carbon steel
Machine diameter	about 11500x1500x1300mm ( LXWXH )
Weight of machine	about 10 Ton
Decoiler	Manual or hydraulic decoiler ( customer can choose )
Weight capacity of decoiler	5ton
Forming station	14
Principle axis	75mm diameter
Forming speed	0-15m/min
Drive Type	1.5' chain transmission
Roller material	GCr15 steel, quenched and heated process
Main power	15KW
Hydraulic power	11KW
Punching	hydraulic punching
Electrical Control	PLC Frequency Control System with touch screen

Profile Drawing

C Purlin Steel Roll Forming Machine With Hydraulic Punching 17 Forming Stations

Work Flowing

Decoiler --- Fedding & Leveling --- Roll Forming --- Punching --- Cut-to-length --- Run out table

C Purlin Steel Roll Forming Machine With Hydraulic Punching 17 Forming Stations

Components

Decoiler ------------------------------------------------1 Unit
Feeding & Leveling --------------------------------- 1 Unit
Main roll forming machine ------------------------- 1 Unit
Hydraulic punching device ------------------------ 1 Unit
Hydraulic cutting device --------------------------- 1 Unit
Hydraulic Station ------------------------------------ 1 Unit
PLC computer control ------------------------------ 1 Unit
Output table ------------------------------------------ 1 Unit

Application

C purlin, c shaped purlin, c channel, lip channel, c section, c profile, c shape, steel c purlin, c purlin steel structure

Advantages

High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

More Machine Pictures
