Metal Roof Panel Roll Forming Machine / Double Layer Forming Machine With Hydraulic Cutting

Metal Roof Panel Double Layer Roofing Sheet Roll Forming Machine With Hydraulic Cutting Thickness 0.4-0.8mm

   Main Specification of Double Layer Forming Machine

• Material thickness: 0.4-0.8mm
• Material width: depend on customer’s requirement
• Decoiler Type: manual or automatical type ( depend on customer’s requirement )
• Weight Capacity Of Decoiler: 5 Ton
• Main Motor Power: 7.5 Kw
• Hydraulic Motor Power: 3 Kw
• Forming Station: approx 18 & 18 ( depend on profile drawing )
• Coil Material: PPGI,GI,Al
• Coil I.D: 470-520MM
• Coil O.D: mAX. 1500mm
• Roller Material: 45#steel, mirror polished with quenched treatment
• Cutting Type: Hydraulic Cutting
• PLC: Panasonic brand
• Inverter: Yaskawa brand
• Touch screen: Mcgs brand
• Operation type: Touch screen & button
• Hydraulic station: Famous Chinese brand

   Working Flow

Decoiler --- Fedding Guide --- Roll Forming --- Cut-to-length --- Run out table

   Main Components

• Decoiler ---------------------------------------------- 1 Unit
• Feeding guide ---------------------------------------- 1 Unit
• main roll forming machine ---------------------------- 1 Unit
• Hydraulic cutting device ------------------------------ 1 Unit
• Hydraulic Station ------------------------------------- 1 Unit
• PLC computer control -------------------------------- 1 Unit
• Output table ----------------------------------------- 1 Unit

   Applications

Metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

   Profile Drawing of Double Layer

   Our Advantages

1. Reasonable price
2. High quality and efficiency
3. 12 months warranty
4. More than 15 years experience
5. Simple structure
6. Low cost and low lose

   Reference Pictures of Double Layer
