Steel Square / Rectangle Downpipe Roll Forming Machine for Making Rainwater Downspout
A). Main Specifications of Downpipe Forming Machine
- Main motor power: 7.5Kw
- Number of forming station: About 20
- Forming speed of downpipe forming machine: 6-12m/min
- Voltage: 380 V, 3 Phase 50Hz ( or depend on customer’s requirement )
- Dimension of machine: About 12000mm*1100mm*1200mm
- Machine wight: about 12 Ton
- Material of Axis: High grade 45# steel
- Diameter of Axis: φ75mm
- Material of Roller: High grade 45#, polished and coated with 0.05mm Chrome Surface.
- Materical of Machine Frame: A3 Steel, thickness 18mm
- Electrical Control: PLC Frequency Control System with touch screen
- PLC: PANASONIC Brand
- Encoder: OMRON Brand
- Transducer: PANASONIC Brand
B). Reference Rainspout Drawings of Downpipe Forming Machine
C). Main Components of Downpipe Forming Machine
- Decoiler ------------------------------------------------ 1 Unit
- Feeding guide ---------------------------------------- 1 Unit
- main roll forming machine ---------------------------1 Unit
- Hydraulic cutting device ------------------------------1 Unit
- Hydraulic Station -------------------------------------- 1 Unit
- PLC computer control -------------------------------- 1 Unit
- Output table -------------------------------------------- 1 Unit
- Elbow machine ----------------------------------------- 1 Unit
D). Working Flow of Downpipe Forming Machine
Decoiler--> Coil sheet guiding and feeding --> Roll forming machine with safty guard--> Tighten Device ->
Cut to length --> Out-put Table --> Curving machine
E). Applications of Downpipe Forming Machine
Rainwater downpipe, downspout, rainspout, water pipe, drainpipe
F). Our Advantages of Downpipe Forming Machine
- High Quality
- Reliable
- Durable
- Reasonable Price
- Good after Service
- 1 Year Warranty
- More Than 10 Years Experience
G). Machine Pictures of Downpipe Forming Machine
H). Factory Pictures & Introduction of Our Company
J). FAQ
Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available.
Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine.
Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.
Q: What size decoiler can you supply us with?
A: From 5-ton decoiler to a 25-ton motorised hydraulic decoiler.
Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.
Q: My current machine rollers need to be replaced. Would you be able to assist me?
A: Yes. Send us your profile and specifications then we will manufacture the rollers for you.
Q: Do we receive any updates while machine is in the manufacturing process?
A: Yes.Regular updates on progress will be sent to you.
